Special Units

In response to various requests from customers;

● Built-in plural mechanisms in one box
● Special housing in appearance
● Special cam motion law
● Long output hollow shaft

From these applications, MYDEX has a wide variety of design, manufacturing and sales records.
Our company has various know-how and solutions from our plenty of experience.
Please consult us when you cosider designs of accurate and high speed automatic machineries for complicated works.

MYDEX can cater to your expectations of "If this is possible" from 1 unit.
Please contact our technical staff.

We would like to introduce our various examples of special secifications as follows.

Special Unit

Built-in plural mechanisms in one box

ワンボックス複数メカ内蔵ワンボックス複数メカ内蔵ワンボックス複数メカ内蔵

You would like to make compact as much as possible of a device that 2 units of indexer are synchronized.   >  Built-in 2 units of mechanism in one box.

Effective in one box
Compact (28% reduction in volume of outer size)
No need for connecting parts, couplings, etc.
No need to adjust timing of 2 units.

Special shafts and additional machining

Chamfering housings

ハウジングの一部を面取した画像

If it is a slight interference, our additional machining is available.



Variant outputs

円筒形出力画像

High rigidity can be obtained for keyless fixture on an output shaft.

Long output hollow shaft

出力軸中空長尺画像

If the specifications are split type of penetrated long output hollow shaft, high accuracy cannot be obtained such as runout of shafts and squareness
and also strength is insufficient, but these can solve the problem using single-piece structure.

Machining and mounting an encoder on the input shaft

入力軸エンコーダー取付加工画像

An encoder is mounted on the input shaft so that the output shaft timing can be synchronized accurately.

Machining to be a stepped input shaft

入力軸段付き加工画像

It can be equiped with a drive train from the counter side of a frange face.

Double output shafts

下面の出力軸を延長した画像

It can be equiped with a drive train from the counter side of a frange face.
